QUAD Multistandar DVB-S/S2/SX/T/T2/C/C2/IP Luminato receiver

Teleste Luminato Multi-standard (DVB-S, DVB-S2, DVB-S2X, DVB-T, DVB-T2, DVB-C, ISDB-T, ITU-T J.83 A/B/C and IP) QUAD Input Module

Teleste Luminato multireceiver is a compact and multifunctional module for Cable TV and IPTV operators. The quad multi-standard receiver module supports DVB-S, DVB-S2, DVB-S2X, DVB-T, DVB-T2, DVB-C, ISDB-T, ITU-T J.83 A/B/C and IP standards. It can be used to receive payload via satellite, terrestrial and cable networks and via IP inputs, either encrypted or free to air. All input alternatives are enabled with software and available without additional software keys/licenses.

Luminato multireceiver supports video resolutions from SD (Standard Definition) to UHD (Ultra High Definition) in MPEG-2, MPEG-4 AVC and HEVC video formats and numerous audio formats such as AAC or MPEG.

The output of the receiver is always fully DVB compatible IP stream with automatically generated PSI/SI tables. The output can be either carried as Multi Pro­gram Transport Stream or de-multiplexed to Single Program Transport Streams, both directly suitable for IPTV networks. They allow highly flexible stream routing and re-multiplexing on Cable TV networks. The IP output streams from the device can be transmitted either directly to another module on the chassis for further processing, to IP connected headend equipment on the local or remote headend, or directly to the IPTV network. Further, each module can create up to 120 output IP streams.

Benefits

• Multiple services per receiver – high efficiency, lower investments
• Two physical ports with dual receivers: Several possible input configurations
• Descrambling on all of the inputs
• IP inputs for encrypted or free-to-air content
• Embedded security – services can’t be accessed in unprotected format
• Hot swap as standard – swap the module and keep the configurations
• DVB-S2X reception for efficient high bitrate satellite video
• Advanced transport stream processing
• Demultiplexing from MPTS to  SPTS
• PID remapping and filtering
• PSI/SI pass-through or regeneration
• Service follow up, service ID remapping, stream type filtering, SID follow up and service information
• Automatic/manual PSI-SI table generation
• Support for numerous CAS
• Multicast and unicast streaming
• MPTS passthrough
• All input alternatives are enabled with software and available without additional software keys/licenses
• High service availability with input stream redundancy
• Emergency video streaming

* Please ask for a quotation from tecnico@anvimur.com
