OTDR + iOLM Tester EXFO FTB-LITE-730D-SM8, FTTx/PON SM 1650 nm
FTB-LITE-730D-SM8
New product
OTDR + iOLM Tester EXFO FTB-LITE-730D-SM8 with permanent connectivity and an advanced port (1310/1550/1650 nm) for FTTx/PON networks.
It offers one-touch automated testing, an 8-inch touchscreen, and a 42 dB dynamic range for fast and accurate fiber characterization.
Reference: FO-EA5801E-GP08-H3
This product is no longer in stock
Data sheet
| GPON | Measuring and Testing |
More info
OTDR + iOLM Tester EXFO FTB-LITE-730D-SM8
The EXFO FTB-LITE-730D-SM8 OTDR is a dedicated Optical Time Domain Reflectometer with permanent mobile connectivity, optimized to perform any passive optical network (PON) and metropolitan network testing in the most efficient, compliant, and secure manner.
Fiber optics increasingly plays an important role in modern telecommunications networks. The requirements for construction, testing, and maintenance of FTTx/MDU links are becoming more prominent. Therefore, the FTB-LITE-730D is designed to solve issues such as lack of procedure compliance, inefficient processes, and delays. It can be used for the characterization, troubleshooting, and activation of both active and dark fiber through the same OTDR port.
The rugged design, with an 8-inch color touchscreen (sunlight-readable) and patented iOLM technology, turns complex tests into automated "Pass/Fail" results with a single touch, eliminating manual trace interpretation and transforming any technician into an expert.
Features
| > Permanent connectivity (Wi-Fi, LTE, BT, GNSS) > 8" sunlight-readable touchscreen. > Up to 10 hours of battery life. > Patented iOLM technology (1-touch). > Swap-Out interchangeable connector. > Dynamic range up to 42 dB. > Event Dead Zone (EDZ) of 0.5 m. > FTTx/PON testing (splitters up to 1x128). > 36-month free data plan. | The OTDR includes 1) iOLM application (Optical Link Mapper) 2) Inline power meter 3) Integrated optical light source 4) RF connectivity (LTE, Wi-Fi, BT, GNSS) 5) Access to EXFO Exchange and FastReporter 6) Calibration certificate 7) USB-A, USB-C, and RJ45 Ethernet ports | Package includes > 1x FTB-LITE-730D-SM8 OTDR > 1x Interchangeable connector (SM8) > 1x Rechargeable LiFePO4 battery > 1x AC/DC adapter > 1x Hand/shoulder strap > 1x Shock protection bag (SPSB) > Access to FastReporter software |
General Specifications EXFO FTB-LITE-730D-SM8
| Dimensions | 198 mm × 249 mm × 71 mm |
| Display | 8-inch color touchscreen, 1280×800 pixels (sunlight-readable) |
| Interfaces | 2×USB-A, 1×USB-C (PD), 1×RJ45 LAN 10/100/1000 Mbit/s |
| RF Communications | Bluetooth, Wi-Fi, 2G/3G/4G LTE, GNSS (GPS/GALILEO/QZSS) |
| Optical Configuration (SM8) | SM OTDR: 1310/1550 nm and 1650 nm (active/filtered) on the same port |
| Dynamic Range | Up to 42 dB (1310 nm) / 40 dB (1550 nm) / 39 dB (1650 nm) |
| Dead Zones | Event (EDZ): 0.5 m | Attenuation (ADZ): 2.2 m | PON: 30 m |
| Power Supply | Input: 100 to 240 V AC, 50 to 60 Hz. Output: USB-C PD (5 to 20 V DC, 45 W max.) |
| Battery | Rechargeable LiFePO4 battery Operating time: up to 10 hours (Telcordia GR-196-CORE) |
| Data Memory | Storage: >20,000 traces (SOR) |
| Environmental Conditions | Operating temperature: -10°C to 50°C Storage temperature: -40°C to 70°C Relative humidity: 0% to 95% (non-condensing) |
| Weight | 2.4 kg (including battery and module) |
| Contents | 1x FTB-LITE-730D OTDR; 1x Interchangeable connector; 1x LiFePO4 battery; 1x AC/DC adapter; 1x Strap/holder; 1x SPSB bag; Access to FastReporter |
