HC220-G5, AC1200 Whole Home WiFi System | TP-LINK

  • Faster Connections: Speeds up to 1200 Mbps—867 Mbps on 5 GHz and 300 Mbps on 2.4 GHz.
  • Boosted Seamless Coverage: Achieve seamless whole home coverage with a clearer and stronger WiFi signal.
  • One Unified Network: Multiple units form a whole-home network that auto-selects the best connection as you move around your home.
  • Enhanced Security: WPA3 encryption, Multi-SSID, and Parent Control provide personalized and safer online experience.
  • EasyMesh Compatible: Provides whole home WiFi coverage with standard mesh technology.
  • Easy Setup: Set up your router in minutes with intuitive Aginet app.
  • TR-069 Remote Management: TR-098, TR-181, TR-111, and TR-143 are supported for automatic provisioning.

More information and downloads HC220-G5-1, here.

Especificaciones

HARDWARE FEATURES
External Power Supply12 V ⎓ 1.0 A
Interface3× Gigabit Ports
1 Port supports WAN/LAN auto-sensing
ButtonReset Button
WPS Button
Dimensions ( W x D x H )3.9 x 3.9 x 3.5 in
(100 x 100 x 89.5 mm)
WIRELESS FEATURES
Frequency2.4GHz and 5GHz
Signal RateAC1200
5 GHz: 867 Mbps (802.11ac)
2.4 GHz: 300 Mbps (802.11n)
Transmit PowerFCC: <30 dBm(2.4GHz), <30 dBm(5GHz)
CE: <20 dBm (2.4GHz), <23 dBm (5GHz)
Wireless SecurityWPA/WPA-PSK2/WPA3 encryptions
Wireless StandardsWi-Fi 5
IEEE 802.11ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHz
Multi-SSID 3× 5 GHz Multi-SSID
3× 2.4 GHz Multi-SSID
SOFTWARE FEATURES
WAN TypeDynamic IP/Static IP/PPPoE
Quality of ServiceWMM
Firewall SecuritySPI Firewall
ManagementLocal Management, Remote Management, TR-069(TR-098/TR-181), TR-111, TR-143
EncryptionWPA/WPA-PSK2/WPA3 encryptions
Advanced FeaturesParental Controls, QoS (Quality of Service), Address Reservation, Port Forwarding,Wi-Fi Schedule
ProtocolsIPv4
IPv6
Working ModesRouter Mode
Access Point Mode
OTHERS
Package ContentsHC220-G5 (1-pack)
1 HC220-G5 Unit
1 RJ45 Ethernet Cable
1 Power Adapter
1 Quick Installation Guide
CertificationsCE, FCC
EnvironmentOperating Temperature: 0℃–40℃ (32℉ –104℉)
Storage Temperature: -40℃–60℃ (-40℉ –140℉)
Operating Humidity: 10%–90% non-condensing
Storage Humidity: 5%–90% non-condensing
Smartphone/Tablet RequirementsAndroid 4.4 or later
iOS 9.0 or later
