NX510v, VoLTE 5G Wi-Fi 6 AX3000 Gigabit Ethernet Router | TP-Link

TL-NX510V

New product

NX510v Router: High-Speed 5G and Wi-Fi 6 Connectivity
Supports VoLTE, AX3000, and Gigabit Ethernet ports
Ideal for modern homes without a fixed-line connection.



Model: TL-NX510V

More details

230,00 € VAT excl.

Add to wishlist

Data sheet

Networking and WirelessExtensores

More info

VoLTE 5G Wi-Fi 6 AX3000 Gigabit Ethernet Router | TP-Link

  • Wi-Fi 6 AX3000 – Fast and Reliable Connectivity for Home or Business:
    Up to 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz.
    Supports technologies such as 1024-QAM, OFDMA, MU-MIMO, Beamforming, Multi-SSID, Guest Network, and WPA/WPA2/WPA3 security.
  • Smart Coverage with EasyMesh:
    Compatible with EasyMesh and 802.11k/v/r protocols to create a flexible Mesh network with seamless roaming between nodes.
  • Full Connectivity – 5G + Gigabit LAN:
    Equipped with 1 auto-sensing 1 Gbps WAN/LAN port and 2 Gigabit LAN ports.
    Internet access via 5G or Ethernet.
    Supports Dynamic IP, Static IP, PPPoE, PPTP, L2TP.
  • Advanced 5G Technology – Superior Speed and Low Latency:
    Compatible with 5G SA/NSA networks with speeds up to 3.2 Gbps and latency as low as 1 ms.
    Also supports 4G LTE (FDD/TDD) and 3G (WCDMA/HSPA+).
    Ideal for fiber-less environments, rural areas, or as a 5G backup for businesses.
  • VoLTE/CSFB Telephony:
    With 1 voice port (RJ11), users can make or receive phone calls over the internet by simply connecting the device to their telephone.
  • Advanced Applications and Features:
    Includes Parental Controls, QoS, Port Forwarding, VPN (IPSec), NAT, SPI/DoS Firewall, SIM management, traffic statistics, SMS/USSD, IPv6, and Wi-Fi scheduling.
    Supports DDNS, IPTV, and cloud firmware upgrades.
  • Aginet App:
    End-user application available for iOS and Android, enabling easy router setup and management—adding value for ISPs by enhancing the user experience.
  • Quick and Easy Configuration:
    With AginetConfig, load configuration files from the app or via TFTP, preventing customers from accidentally resetting the settings.
  • Professional Remote Management:
    Compliant with TR-069, TR-098, TR-181, TR-111, TR-143, and TR-369 (USP) standards.
    Supports remote management via WebUI, HTTPS, SNMP, and cloud.
  • TAUC Management Platform Compatibility:
    Fully compatible with TAUC (TP-Link Aginet Unified Cloud), which—beyond TR-369 USP remote management—includes Wi-Fi Analytics features to enable proactive support and continuous service optimization.

Specifications

HARDWARE FEATURES

CPU1 GHz Dual-Core CPU
Interface3× 10/100/1000 Mbps RJ45 LAN Ports
(1 port with WAN/LAN auto-sensing)
Buttons1 RESET/Wi-Fi multiplex button & 1 WPS button
External Power SupplyOutput: 12V/2A
Input: 100-240V~50-60Hz 0.8A
Dimensions3.9 × 3.9 × 7.56 in (99 × 99 × 192 mm)
AntennasInternal Wi-Fi antennas; optional internal/external LTE/5G antennas

WIRELESS FEATURES

Wireless StandardsIEEE 802.11a/n/ac/ax 5GHz,
IEEE 802.11b/g/n/ax 2.4GHz
Frequency2.4 GHz and 5 GHz
Signal Rate5G SA: 2.4 Gbps (downstream) / 900 Mbps (upstream)
5G NSA: 3.4 Gbps (downstream) / 550 Mbps (upstream)
LTE: 1.6 Gbps (downstream) / 200 Mbps (upstream)
Wireless SecurityWPA/WPA2-PSK/WPA3 encryption
Transmit PowerCE: ≤20dBm (2.4GHz); ≤23dBm (5G band1/band2);
≤30dBm (5G band3)
RCM: ≤30dBm (2.4GHz); ≤23dBm (5G band1/band2);
≤30dBm (5G band3/band4)
Network Type5G:
N1/N3/N5/N7/N8/N20/N28/N38/N40/N41/N77/N78

4G:
FDD-LTE: B1/B3/B5/B7/B8/B20/B28
TDD-LTE: B38/B40/B41/B42/B43

3G:
DC-HSDPA, HSPA+, HSDPA, HSUPA, WCDMA B1/B5/B8
Mesh Technology802.11k/v/r, EasyMesh support

SOFTWARE FEATURES

Working Mode5G/4G/3G Wi-Fi Router
Multi SSID3 additional 2.4GHz/5GHz networks
FeaturesParental Controls, QoS (Quality of Service), Address Reservation,
Port Forwarding, Dynamic DDNS, SIM Management, SMS,
Cloud Upgrade, EasyMesh, VoLTE, IPTV, IPv6, NAT Forwarding,
Firewall, LED Control, Network Diagnostic, CWMP, SNMP,
Traffic Statistics, WPS, 1024-QAM, OFDMA, IPSEC VPN, Web Remote Control
WAN TypeDynamic IP / Static IP / PPPoE / L2TP / PPTP
ProtocolsSupports IPv4 and IPv6

OTHER

CertificationsCE, RoHS
Package ContentsNX510v 5G AX3000 Wi-Fi 6 Router
1× RJ45 Ethernet Cable
1× Power Adapter
1× RJ11 Cable
1× Quick Installation Guide
System RequirementsMicrosoft Windows 98SE, NT, 2000, XP, Vista™, or Windows 7, 8, 8.1, 10,
macOS, NetWare, UNIX, or Linux
Browsers: Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 or higher.
Environmental FactorsOperating Temperature: 0°C ~ 40°C
Storage Temperature: -40°C ~ 70°C
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing

Accessories

Download

NX510v Datasheet

Download (1.3M)
