Overlight CWDM Optical Transmitter, Indoor use, 2SAT+DTT (ICT-2), 1310nm, Optical power 10dBm

• CWDM optical transmitter for satellite and terrestrial signals, specifically designed for installations compliant with ICT-2 regulations. Receives one polarity and one band from each of the two satellites, as well as the terrestrial signal, to multiplex and transmit them to up to 64 users through a single fiber output at 1310nm, with 10dBm optical power.
• Thanks to its optimized electronic performance and low losses, it reduces the need for amplifier devices and simplifies deployment in collective installations, preserving signal quality end-to-end.
• Part of the comprehensive Overlight series, responsible for distributing satellite and DTT signals to multiple users through a single optical fiber.
• Allows signal amplification for enhanced performance.

Highlights

• Independent inputs for each satellite (FI) and terrestrial signal
• High output level, ideal for collective installations of up to 64 users
• Compatible with Quattro offset LNB (ref. 747701)
• Low losses and optimized electronic performance
• Very lightweight and compact size (137x126x45mm)
• 100% European design, quality, and manufacturing
• High-shielding Zamak chassis
• SC/APC optical connector
• "F" type RF connectors (female)
• Wall-mounted installation
• Includes power supply and adapter cable for F connector input
• DC pass-through from satellite (FI) and terrestrial inputs to amplifier or LNB
• Signal status indicator LED
